Whirlpool Bath Pump , Series DXD-310E
Request a Quote
Working conditions
- Medium temperature: 5-50℃
- Environmental temperature: ≤50℃
- Humidity: 65% RH
- Maximum working pressure: 0.4MPa
With proven product quality and performance, we are confident to offer:
- Pool equipment wholesale for distributors
- Everything needed from pool and Spa equipment to pool accessories for pool & Spa contractor
- OEM service for branded suppliers and manufacturers of pool equipment and supplies
- Manufacturing service of pool equipment and supplies for the factories with limited production capacity and product variations.
Technical data
| Model | Voltage | Power | Rotating speed(r/min) | Maximum Lift(m) | Maximum flow(l/min) | Insulation class | Protection grade | Gross weight(kg) | Certification | |
| KW | HP | |||||||||
| DXD-310E | 230V/50Hz | 0.75 | 1.0 | 2850 | 10.0 | 300 | F | IP X5 | 8.0 | CE TÜV |
| DXD-310F | 230V/60Hz | 0.75 | 1.0 | 3450 | 10.0 | 300 | F | IP X5 | 8.0 | KC |
| DXD-310-750 | 115V/60Hz | 0.75 | 1.0 | 3450 | 10.0 | 300 | F | IP X5 | 8.0 | UL |
| DXD-312E | 230V/50Hz | 0.9 | 1.2 | 2850 | 11.0 | 317 | F | IP X5 | 9.2 | CE TÜV |
| DXD-312F | 230V/60Hz | 0.9 | 1.2 | 3450 | 11.0 | 317 | F | IP X5 | 9.2 | |
| DXD-315G | 115V/60Hz | 0.9 | 1.2 | 3450 | 11.0 | 317 | F | IP X5 | 9.2 | |
| DXD-315E | 230V/50Hz | 1.1 | 1.5 | 2850 | 12.0 | 342 | F | IP X5 | 9.6 | CE TÜV |
| DXD-315F | 230V/60Hz | 1.1 | 1.5 | 3450 | 12.0 | 342 | F | IP X5 | 9.6 | |
| DXD-310-1100 | 115V/60Hz | 1.1 | 1.5 | 3450 | 12.0 | 342 | F | IP X5 | 9.6 | UL |
Packing: 400mm×170mm×220mm Container: 20＇: 1600pcs 40＇ 3000pcs
Optional function: timer & no water protection
