8-Color Stack Flexographic Printing Machine

8-Color Stack Flexographic Printing Machine
Request a Quote

Acceptable Printing Materials of the Eight-color Stack Flexographic Printing Machine
LDPE: 50 ~ 160μm
LLDPE: 48 ~ 158μm
HDPE: 50~ 162μm
PVC: 50 ~ 160μm
CPP: 48 ~ 165μm
PP: 50 ~ 165μm
NY: 48~ 165μm
PETP: 40 ~ 168μm
OPP: 40 ~ 165μm
BOPP: 40~ 160μm
OPA: 40 ~ 165μm
Plating film: 40~ 170μm
Aluminum: 45 ~ 165μm
Cellophane: 35 ~ 180g/m2
Paper: 35~ 180g/m2
Wrapping paper: 35 ~ 180g/m2

Features of the Eight-color Stack Flexographic Printing Machine
1. The printing machine have one unwinder and one rewinder.
2. Slow speed and full load startup; stable running by auto tension control can decrease noise when increasing or decreasing speed.
3. High dots presentation rate; clear and vivid stratification of screen printing; strong stereo effect and accurate registering.
4. Aluminum roller adopts the Japan semi-sealing small bearing; flinty oxidation, static and dynamic balancing treatments are conducted; low resistance and small flop.
5. Adopted special modulus angular gears, so the printing machine can provide accurate printing size and full printing specifications.
6. With the air exhaust, blowing and heating settings; the heating system adopts the central thermostatic control system and group management, also with the cold air forming devices.
7. When the machine is stopped working, printing rolls can still keep moving.
8. Air shaft is used in material holder.
9. The chamber doctor blade system contains ink container and circulating pump.
10.Plastic roller and grain roller are used to smearing the ink.
11.Accurate printing size can be presented by the special vertical gear transmission device.
12. The machine is equipped with blower and heater; and the heater employed central constant temperate controlling system.
13.Germany particular steel material processed bottom roller: The grouped and controlled bottom roller is processed with special techniques and electrically gilded with 0.1mm hard chromium protective layers.
14. The unwinder has auto deviation correction system.
15. One set of printing cylinder (size: 15 inches)

Performance and Parameters of the Eight-color Stack Flexographic Printing Machine
Printing color 8 colors (Reversible printing 8 color press for 1 7, 2 6, 3 5, 4 4, 8 0 )
Printing width 1000mm
Web path width 1050mm
Printing length 190 ~ 1016mm (7.5"~ 40")
Highest machine speed 90 meters per minute
Highest printing speed 60 meters per minute
Plate thickness 2.28mm
Ceramic anilox 200LPI 2PCS Japan
300LPI 2PCS Japan
500LPI 4PCS Japan
Register precision Longitude ±0.15mm
Transverse ±0.15mm
Unwind reel diameter Φ600mm
Rewind reel diameter Φ600mm
Unwind 2PCS
Rewind 2PCS
Tension scope 3 ~ 50kg
Tension precision ±0.3kg
Unwind and rewind web cylinder Φ76mm (inner diameter)
Unwind and rewind material holder Air shaft
Press power Mechanic control
Inking Auto cyclic system, one diaphragm pump
Inking distributing deceleration motor (reduction ratio 1 : 50)
Drying model Electric heating /Infrared(hot air)
Bearing: NSK (Japan)
One direction bearing ASNU (Germany)
Drying power 26kw
Air blower (large) 1.1kw / 4 pcs
Air blower (small) 1.5kw / 2 pcs
Master motor power 7.5kw (reduction ratio 1 : 5)
Machine power 42kw
Outline dimension 5.4m×2.4m×3.3m
Deviation correction system Auto hydraulic pressure
Power Voltage 220/380V, 3 PH, 60/50 HZ
