LCD Display Fan type Hot Air Soldering Rework Station with Smoke Absorber, Item WEP 992DA Manufacturer

LCD Display Fan type Hot Air Soldering Rework Station with Smoke Absorber, Item WEP 992DA

Request a Quote

View All: http://yihua-soldering.com/2-1-wep-992da-hot-air-soldering-station.html

Description
The WEP 992DA hot air soldering station is an upgraded version of our 992DA hot air soldering station that features a personalized oblique display screen deign, and we added a 3-segement storage button to memorize all functions for different parameters. By pressing the switch button, you can quickly retrieve the corresponding parameters such as airflow rate, air gun temperature, soldering iron temperature, hot/cold air mode, etc.

Technical Parameters

Parts parameters: Hot air gun

Work voltage: AC 220V±10% 50Hz
Output power: 550W
Temperature range: 100℃～480℃
Airflow type: Diaphragm pump
Air Flow: 28L/min (MAX)
Temperature Stability:±1℃ (Static)
Display Type: LCD display
Temperature correction type: The PID digital program proofreading
PID Temperature correction cycle: rapidly 20ms
Heating elements: Ceramic skeleton heater
Standard nozzles/tips: (10mm,8mm,5mm,3mm,13mm) 5PCS nozzles

Parts parameters: Soldering iron

Work voltage: AC 220V±10% 50Hz
Output power: 75W
Temperature range: 200℃～480℃
Temperature Stability:±1℃ (Static)
Display Type: LCD display
Temperature correction type: The PID digital program proofreading
PID Temperature correction cycle: high-speed 100ms
Heating elements: Imported heater
Standard nozzles/tips: B

Details

Standard Configuration

Machine: 1 set
Power Cable: 1 pc
Iron Handle (including a heater and tip): 1pc
Air Gun Handle: 1pc
Ferroalloy Iron Holder: 1pc
Thermal Resistant Sponge: 1pc

Air Nozzle: 5pcs
Smoke Absorption Sponge: 5pcs
IC Extraction Tool: 1pc
Instruction Book: 1pc
