The heat pipe is a tube with internal vacuum and certain working medium, which is a heat superconductor. Its heat transfer rate is 1000 times that of silver. Compared with the general all glass vacuum tube, the heat pipe has more advantages like high heating speed, no scale formation, glass breakage prevention, water filled time unlimited, single broken tube having no influence on machine use.

Himin gravity heat pipe is made of oxygen-free copper TU1, copper content up to 99.97%, which is the most suitable shell material in current market.

Copper Mark	TU1	T2	TP2	Copper Recycled
Material Component	Cu≥99.97%	Cu≥99.90%	Cu≥99.85%	Component can't be assured.
	P≤0.001%	P≤0.001%	P≤0.01%
	O≤0.001%	O≤0.06%	O≤0.01%

Specifications of Himin Heat Pipe

Product specifications	Material	Outer diameter(mm)	Wall thickness(mm)	Length of variable diameter(mm)	Wall thickness of variable diameter
HMB8-1600/58	TU1	Ф8	0.7	58	1
HMB8-1600/66	TU1	Ф8	0.7	66	1
HMB8-1800/58	TU1	Ф8	0.7	58	1
HMB8-1800/66	TU1	Ф8	0.7	66	1
HMB8-2100/58	TU1	Ф8	0.7	58	1
HMB8-2100/66	TU1	Ф8	0.7	66	1
HMB8-2000/80	TU1	Ф8	0.7	80	1
HMD8-1850	TU1	Ф8	0.7	/	/
HMD8-2200	TU1	Ф8	0.7	/	/
HMD8-1900	TU1	Ф8	0.7	/	/
HMD8-1700	TU1	Ф8	0.7	/	/
