Overlock Sewing Machine, HX6900TA KSC/AK Manufacturer

Overlock Sewing Machine, HX6900TA KSC/AK

Request a Quote

View All: http://hikarisewingmachine.com/2-3-direct-drive-cylinder-bed.html

Computerized high speed direct drive cylinder bed overlock sewing machine

Introducing our computerized direct drive overlock sewing machine that features a narrow cylinder design. With its small cylinder bed, this machine enables high-speed overlock operations in small sewing areas. It excels in sewing children's garment cuffs, lingerie elastic tape, gloves, and other delicate items, elevating both production efficiency and sewing precision.

Specifications

Model	HX6904TA-02KSC/AC	HX6914TA-03KSC/AK	HX6914TA-04KSC/AK
Needle	DCx27 #10	DCx27 #11	DCx27 #11
No. of needles	1	2	2
No. of threads	3	4	4
Needle pitch	0	2	2
Stitch width	4mm	4mm	4mm
Stitch length	0.7-3.8mm	0.7-3.8mm	0.7-3.8mm
Differential ratio	0.8-1.8	0.8-1.8	0.8-1.8
Presser foot lifting height	5.5	5.5	5.5
Light	√
Medium		√
Heavy			√
Speed (S.P.M)	7000 r/min	7000 r/min	7000 r/min
Dimensions	530x370x555mm	530x370x555mm	530x370x555mm

Features

2. Compact and Precise The 148mm cylinder bed circumference allows seamless adaptation to small and challenging sewing processes.
2. Integrated Design Upgraded with an integrated design, improving both hardware and software performance and sewing quality.
