High-Temp Box Furnace

Request a Quote

View All: http://heating-melting.com/2-4-1-high-temp-box-furnace.html

Heating and Melting Equipment

Customizable high temperature box furnaces manufactured to meet your exact specifications

The high temperature box furnace uses heating elements made of an electrothermal alloy wire that is resistant to high temperatures and has an operating temperature of up to 1200℃. It is an ideal choice for industrial use for quenching and heating of general metal or alloy steel parts. If necessary, a shielding gas can be introduced to reduce part oxidation. The cantilever door keeps the heat away from the operator, ensuring furnace safety.

Features

The RX3 series box-type resistance furnace casing is welded using angle steel and steel plates, with the furnace lining typically made of a 0.6g/cm3 micro-bead refractory brick that is ultra-light and energy-saving. Insulating materials such as aluminum silicate fiber and expanded vermiculite powder are used between the outer casing and the lining, ensuring the lining is an energy saving furnace liner.
Made of electrothermal alloy wire resistant to high temperature, the heating element is installed on the left, right, and bottom of the furnace. The workpiece is heated on the bottom plate of the heat resistant steel furnace, while temperature rise of the furnace door is achieved using a handheld sprocket. Furnace temperature and over temperature protection are controlled using the temperature control cabinet.
The stepping control and thyristor control for the control cabinet are optional and customizable upon request.

Parameters

Model		RX3-20-12	RX3-45-12	RX3-65-12	RX3-90-12	RX3-115-12
Rated power (KW)		20	45	65	90	115
Rated temperature (℃)		1200	1200	1200	1200	1200
Wiring method of heating element		Series	Y	△	△△	△△
Chamber size	Length (mm)	650	950	1200	1500	1800
	Width (mm)	300	450	600	750	900
	Height (mm)	250	350	400	450	550
No-load heat-up time (h)		≤3	≤3	≤3	≤4	≤4
No-load power loss (kw)		≤7	≤13	≤17	≤20	≤22
Uniformity of furnace temperature (℃)		≤20	≤20	≤20	≤20	≤20
Max. Loading (kg)		50	100	200	400	600
Dimensions	Length (mm)	1660	2050	2300	2950	3250
	Width (mm)	1560	1700	1970	2300	2400
	Height (mm)	1900	2170	2290	2300	2550
Furnace mass (kg)		1500	2200	2600	4000	5000
