Automatic Tape and Reel Machine
Request a Quote
Model: AM-CB-20
JDL Automatic Tape and Reel Machine is ideal for the electrical performance test, appearance inspection and tape packing of molded inductor and NR series inductor products. This machine adopts vibratory bowl feeder feeding and tests the produced inductor for electrical performance, including withstand voltage, polarity and other testing. After that, it will perform automatic packing and cutting. This machine can protect the inductors from abrasion and crack during the testing and packing, offering high versatility.
Product Details:
Technical Parameters
| Feeder | Vibratory Bowl Feeder |
| Packaging Method | Automatically |
| Testing Project | Electrical performance test |
| Capacity | 4-12Kpcs/h |
| Application | Molded inductor, NR inductor |
| Control Method | PLC controlled |
| Temperature | -5℃-50℃ |
| Size(L*W*H) | L1200 * W780 * H1500mm |
| Power supply | Single phase AC220V/50HZ |
| Air supply | 0.4—0.7mpa |
| Power consumption | 2.5kW |
| Weight | About 350kg |
