Edge Sander
Request a Quote
Edge sanders are used to process different, irregularly shaped wooden workpieces and sand their edges. They are especially suited to processing long strip workpieces like dining table legs and chair legs. After workpieces have been shaped, this sander will carry out sanding to achieve round, smooth, and perfect edges. PLC controlled, this sander is easy to operate, learn, and adjust. It is capable of sanding different edges according to different materials, adjusting the edges within 1 to 3mm.
Main components of the edge sander, including the motor, rubber feeding roller, electrical control components, and frequency convertor, are imported worldwide with a high quality, high stability, and exceptional safety.
Specification| Model | MD-40 |
| Spindle horsepower | 2.2KW×1 |
| Feeding horsepower | 180W×4 |
| Feeding speed(inverter speed) | 6-15m/min |
| Minimum sanding length | 370mm |
| Maximum sanding width | 70mm |
| Maximum sanding height | 70mm |
| coir dimensions | 1260×68mm |
| Vacuuming mouth size | 4 inch×1 |
| Mechanical dimensions(L×W×H) | 1050×950×1400mm |
| Machine weight | 280KG |
