The nitrogen purge cabinet is used for dehumidification and preventing oxidation after usage with a nitrogen system. The nitrogen purge cabinet can be linked to bottled nitrogen, nitrogen generator, nitrogen tanks and other nitrogen equipment. The nitrogen inlet diameter is 6mm, and equipped with an electric valve.Application:
The nitrogen purge cabinet is used for storing oxidizable products, such as semiconductors, electronic components, LCD glass substrates, optical films, instruments and more.

Parameters:
Humidity Control Range: 5%RH-Current Ambient Humidity.
Humidity Fluctuation: ±3%RH.
Temperature Control Range: Ambient Temperature ±3%℃
Voltage: 100V-220V

Model Specification Layer Doors
XZNC-43L W400mm×D400mm×H560mm(External) W350mm×D280mm×H435mm(Internal) 1 Single
XZNC-80L W400mm×D400mm×H980mm(External) W350mm×D280mm×H815mm(Internal) 3 2
XZNC-134L W450mm×D450mm×H1000mm(External) W400mm×D400mm×H835mm(Internal) 3 Single
XZNC-235L W604mm×D420mm×H1310mm(External) W554mm×D370mm×H1145mm(Internal) 3 2 (up and down)
XZNC-284L W900mm×D450mm×H1000mm(External) W850mm×D400mm×H835mm(Internal) 3 2 (left and right)
XZNC-375L W604mm×D550mm×H1520mm(External) W554mm×D500mm×H1355mm(Internal) 4 2 (up and down)
XZNC-362L W600mm×D450mm×H1800mm(External) W554mm×D400mm×H1635mm(Internal) 5 3 (up, middle and down)
XZNC-528L W1000mm×D500mm×H1400mm(External)W950mm×D450mm×H1235mm(Internal) 4 2 (left and right)
XZNC-660L W1200mm×D450mm×H1600mm(External)W1150mm×D400mm×H1435mm(Internal) 4 4 (2 left and 2 right)
XZNC-1012L W1200mm×D600mm×H1800mm(External)W1150mm×D550mm×H1600mm(Internal) 5 4 (2 left and 2 right)
XZNC-1248L W1250mm×D700mm×H1800mm(External)W1200mm×D650mm×H1600mm(Internal) 5 6 (3 left and 3 right)
