Semi-Automatic Linear Bottle Blowing Machine
The semi-auto linear blow molding machine is ideally suited for small-batch production of plastic bottles and containers used in packaging applications for food, pharmaceutical, cosmetic, pesticide, chemical and soft drinks. This bottle molding machine is perfect for applications aiming to obtain savings in energy, space, investment cost, as well as high production efficiency.
Specifications
| Model | JR-8Y | |
| Container | Product material | PET |
| Volume | 0.1L-2L | |
| Theoretical output | 1200 b/h | |
| Preform length | 15mm-350mm | |
| Preform inner diameter | Ø5mm-38mm | |
| Mold | Max. mold plate size (L×W) | 350x380mm |
| Max. mold thickness | 180mm | |
| Clamping force | 45kN | |
| Mold opening stroke | 160mm | |
| Machine | Machine dimensions (L×W×H) | 160x60x161cm |
| Machine weight | 500kg | |
| Heater (L×W×H) | 187x63x145cm | |
| Heater weight | 250Kg | |
| Power | 17.5kW | |
Features
- Equipped with microcomputer control unit, easy to operate;
- Infrared heating system adopts imported SCR controlled IR heating tube;
- Reliable three-phase motor is used to control moving part, and driven by frequency converter;
- There are two left/right cylinders to control stretching and sealing, the stretching length is adjustable automatically; Air blowing retention time can be adjusted to ensure better bottle blowing process;
- The waste air is exhausted through a silencer inside the bottle blower machine, thereby reducing noise to a minimum level;
- Air storage unit and high/low pressure-reducing valves are configured to provide better performance;
