Overwrapper, Type BT-2000A/B

Overwrapper, Type BT-2000A/B
Overwrapper, Type BT-2000A/B
Overwrapper, Type BT-2000A/B
Request a Quote

This BT-2000A/B automatic packaging cellophane overwrapping machine uses environmentally friendly OPP or BOPP thin film for packaging hard cartons in a variety of specifications. It carries out organization, packing, heat sealing and counting of cartons. This is done while automatically applying tear tape with anti-counterfeit for easy opening that give the package an excellent moisture and pollution resistance, without sacrificing the easy to use structure.

Application:
This BT-2000 A/B automatic packaging cellophane overwrapper is suitable for the wrapping of pharmaceutical products, health care products, VCD magnetic tapes, pokers, daily cosmetics, cigarettes, tea leaves, foods, office supplies and other small-scale or middle-scale boxed items.

Parameters
Productivity 20-60 packs/min
Packing dimensions (40-180)×(20-120)×(10-60)mm
Power supply 220V 50Hz
Motor power 0.75kw
Power during electric heating 4kw
Dimensions 2400×800×1560mm
Weight 800kg
Features:
  • The BT-2000A/B automatic packaging cellophane overwrapping machine uses a mechanical connecting rod driving mechanism, which is not only reliable but durable.
  • It uses a stepless variable frequency conversion technology, and is equipped with a fully automatic PLC control system, in order to achieve heat sealing, reshaping, automatic temperature control and automatic feeding.
  • The touch screen displays a number of functions, including program settings, control operation, tracking display, final counting, emergency stop and more.
  • Within a designated range, multiple packing specifications in one machine can be set and adjusted, saving the customer money.
  • The equipment features a dual transition between manual and automated control, which customers can choose from based on their needs.

Optional equipment
PLC; Electro-optical tracking system; Coding machine

WISELY offers a wide range of pharmaceutical machinery like capsule filling machines, tablet polishers, and pharma packaging machines. The company was founded in 1992 and is a member of the China Association for Pharmaceutical Equipment. We participate in continuous development and have many patents for technologies used in our capsule fillers. We provide customers with high quality pharmaceutical and medical equipment all over the world.
