Paper Cup Making Machine

Paper Cup Making Machine
Request a Quote

The JBZ-A paper cup making machine is an ideal product for paper cup making due to its automatic function and multi-working station. It produces one-side film-coated paper cup through the procedure of automatic paper feeding, oil silicon lubrication, bottom punching, heating, knurling, curling and cup discharging.

Specifications
Model JBZ-A04 JBZ-A12 JBZ-A16 JBZ-A22
Specification of paper cup 2oz, 4oz, 4.5oz, 6.5oz 6oz, 8oz, 9oz, 12oz 8oz, 9oz, 12oz, 16oz 8oz, 9oz, 12oz,16oz
Paper material Single-side PE coated paper
Outer diameter of cup rim 50-80 50-95 50-95 50-95
Outer diameter of cup bottom 35-70 35-70 35-70 35-70
Cup height 30-60 50-120 80-150 100-175
Bottom depth ≤10 ≤10 ≤10 ≤12
Taper angle 4-6° 2-8° 2-8° 2-8°
Productivity 40-50pcs/min 35-45pcs/min 35-40pcs/min
Power supply 380V 50Hz
Total power 5kW 6kW
Weight 1600kg 1900kg
Packing size(L×W×H) (mm) 2800×1350×1760
730×600×1100
- 3000×1350×1900
730×600×1100
3300×1450×2000
730×600×1100
