Application
The end face milling machine is mainly used for end face milling of box girder, H beam, foundation, valve etc. It can realize automated milling with high efficiency and high precision. The max dimension of the end face of workpiece which can be milled is 1500×1200mm.

Technical parameter
Max width 1500 mm
Max height 1500 mm
Max depth 1500 mm
Plate thickness 4-80mm
Material to be processed Q235A, Q235B, Q345, Q420C

Technical features
1. The end face milling machine consists of milling head, lifting pillar, sliding table, lathe bed, mechanical feeding system, electrical control system, rail protective device, cutter etc.

2. The lathe bed of the hydraulic press device adopts welded structure. And it is aging treated integrally after welding.

3. The milling head is the gantry heavy milling head imported from Taiwan. It has the following features: reasonable structure, reliable performance, large range of speed variation, good rigidity, low noise, high efficiency, convenient operation.

4. The sliding table adopts integrated design and manufacturing of superior carbon steel. The structural components are designed according to the intensity of heavy end face milling machine. The welding finished structure will be aging treated and then metal processed, so that it has the following features: compact structure, good rigidity and stability. It can form sliding pair with the lathe bed of which the rail is large rectangle with good load capacity and high guide precision; it also has good lubrication condition. The sliding table is driven by mechanical feed drive system through trapezoid screw nut in order to realize fast forward, work feeding, quick return. The sliding table is equipped with milling head, and drives it to realize milling, resetting and up-and-down motion. The operation cycle of sliding table is controlled by mechanical drive system and electrical control system.

5. The protection unit of the rail adopts retractable, telescopic form steel plate cover which is well sealed and has good heat dispersion and long service life. There is a peephole on the fixed protection cover which can be used to monitor the lubrication situation and cleanness of the rail or add lubricating oil to the rail of lathe bed. The peephole is equipped with a small cap which can be used to cover the peephole after use. Because this machine adopts low speed travel, so it adopts concentrated mechanical lubrication device. The lubricant pump is installed at the right rear side of the feeding unit. It can supply oil to the rail for lubrication at regular time and in a fixed quantity according to requirements when the lathe is running, so that it is quite convenient and fast.

Jinfeng introduction
Jinfeng has 2 large specified accessory warehouse with sufficient stock, so that we can provide service in time.
We have a stable sales team. All the members of the sales team have more than 10 years of experience in service, so that they can provide customers with various consultation and services rapidly, in time and expertly. Our executive vice president leads an after-sales service team of 30 employees, so that they can provide 24-hour after-sales service all year round.

Jinfeng Welding & Cutting Machinery Manufacture Co., Ltd hires senior engineers from ESAB to lead mechanical department, electrical department and software department. There are 80 people in the team in total. They will carry out development and design of various structural steel H beam production lines, so that we have technical guarantee.

Jinfeng has strong production capacity: we have 13 imported CNC machining centers, 3 4mx12m large machining centers and 300 equipment sets such as CNC grinding machine, drilling machine and milling machine etc.

We also have specified hardware processing workshop, plate welding workshop, assembly shop, packaging shop, painting and drying shop etc.

The key part of the complete end face milling machine is rack assembly which is carried out by CNC machining center.

Meanwhile, it can be multi-surface processed. So the installation precision and machine service life can be ensured.

We have a technical team with 80 employees, providing R&D, design, training and after-sales service.
