Oscillating Granulator, Granulating Machine YK Series
Request a Quote
Oscillating granulator, or YK series granulating machine is widely used in pharmaceutical, chemical, foodstuff, and other industries for the production of granules from wet powder materials. It is also used to grind block-shaped dry materials.
Parameters of Oscillating Granulator, Granulating Machine YK Series
| Type | YK60 | YK-100 | YK-160 |
| Production capacity(kg/h) | 20-25 | 30-200 | 200-300 |
| Motor power(kw) | 0.37 | 1.1 | 2.2 |
| Barrel speed (r/min) | 46 | 55 | 55 |
| Vibration Angle | 360° | 360° | 360° |
| Barrel diameter(mm) | Ф60 | Ф120 | Ф160 |
| Overall size(mm)（L×W×H） | 530×400×530 | 700×400×1050 | 1000×800×1300 |
| Weight(kg) | 70 | 280 | 450 |
