2000 Series Water Well Drilling Rig
Request a Quote
Well drilling equipment for drilling depths up to 2000m with a borehole diameter range of 105-1000mm
The 2000 series water well drilling rigs are equipped with advanced hydraulic components sourced from international brand suppliers.
These components effectively minimize breakdowns, enhance durability, and reduce equipment weight.
The rig’s lifting capacity reaches 100 tons, the maximum borehole diameter is 1000 mm, and the maximum drilling depth is 2000 m.
It is also fitted with a rotatable control console, providing a more user-friendly solution to visibility and angle requirements during operation.
Technical Parameters
| Parameter | Unit | SL2000 |
| Max. drilling depth | m | 2000 |
| Drilling diameter | mm | 105-1000 |
| Recommended air pressure | MPa | 1.65-8 |
| Recommended air consumption | m³/min | 16-120 |
| Drill pipe length | m | 6 |
| Recommended drill pipe diameter | mm | 127 |
| Axial pressure | t | 19 |
| Lifting force | t | 100 |
| Fast lifting speed | m/min | 30 |
| Fast feeding speed | m/min | 38 |
| Max. rotary torque | N·m | 36500 or 29000 |
| Max. rotary speed | r/min | 50/100 or 62/124 |
| Main auxiliary winch lifting force | t | 4 |
| Small auxiliary winch lifting force | t | 1.5 |
| Jack stroke | m | 1.7 |
| Drilling efficiency | m/h | 10-35 |
| Traveling speed | km/h | 5 |
| Gradeability | ° | 21° |
| Rig weight | t | 36 |
| Overall dimensions (L x W x H) | m | 12x2.6x3.6 |
| Working conditions | Unconsolidated formations and bedrock | |
| Drilling method | Top drive hydraulic rotary and feed; DTH hammer or mud drilling | |
| Matched DTH hammer | Medium- and high-pressure series | |
| Optional accessories | Mud pump, centrifugal pump, generator, foam pump | |
