Dynamic CO₂ Laser Marking Machine
- Laser power 100 / 150 / 250 / 300W
- Repeat Precision ±0.01mm
- Laser Wavelength 10.64μm
- Engraving Depth ≤2 / ≤3 / ≤5 / ≤8mm
The dynamic CO₂ laser marking machine features a compact, fully integrated design that reduces footprint by 40%. Its user-centric layout includes an adjustable-angle display for both seated and standing operation, minimizing neck strain. The built-in keyboard aligns flush with the machine’s frame to prevent accidental bumps, while tactile knobs and physical buttons retain the familiarity of traditional controls—ideal for new users. Equipped with universal casters and brake locks, the machine can be easily repositioned to adapt to production line adjustments.
Suitable for marking, cutting, and drilling various non-metallic materials, such as wood, paper, fabric, acrylic, leather, plastic, rubber, resin, ceramics, coated materials, stone, and more.
| Model | LS-CO2-100W ,150W,250W,300W |
| Laser Power | 100Watt 150Watt 250Watt 300Watt |
| Laser Generator | CO2 Metal Laser Tube |
| Laser Wavelength | 10.64μm |
| Engraving Line Speed | ≤5000mm/s |
| Repeat Precision | ±0.01mm |
| Minimum Line Width | 0.1mm |
| Minimum Character | 0.4mm |
| Marking The Maximum Height | 800*800mm |
| Power Supply | 220V/50Hz or 110V/60Hz |
| Engraving Depth | ≤2mm/ ≤3mm/ ≤5mm/ ≤8mm |
| Cooling System | Water cooling |
| Instructions | Video instructions&instructions book |
| Power Consumption | 500W/1000w |
| Repeat Frequency | 20-100KHz |
| Standard Engraving Range | Within 500*500 800mm*800mm |
RF CO₂ laser
Utilizes an industry-renowned imported coherent laser source, known for its high electro-optical conversion efficiency and excellent performance. It requires virtually no maintenance, is suitable for high-volume production needs, and supports 24-hour continuous operation without malfunction.
2.5D Galvo scanner
Employs dynamic focusing technology, integrating an electrically adjustable lens to quickly adjust the laser focal position without relying on mechanical moving parts, achieving a Z-axis working range of up to 100mm.
Z-axis lifting platform
Features a dual-rail design, fixed with screw spacing to ensure the platform remains horizontally stable during lifting and lowering, preventing tilting or wobbling. Paired with wear-resistant copper nuts, it enhances transmission precision and lifespan, reducing mechanical wear. Some high-end models may combine electrically adjustable focusing lenses with the galvo system to achieve Z-axis dynamic focusing, replacing traditional mechanical lifting and expanding the focusing range (e.g., ±21mm).
- CO₂ laser
- Laser control cabinet
- Honeycomb panel workbench
- 2.5D dynamic focusing galvo scanner head
- F-theta lens
- Control card
- Laser power supply
- Computer
- Power cord
- Water chiller
- Safety goggles
- Foot pedal switch
- Hex key tool set
- Equipment warranty certificate
- Shipping accessories list
- Product catalog
