Aluminum Hollows- Aluminum Round Tubes Manufacturer

Aluminum Hollows- Aluminum Round Tubes

Request a Quote

View All: http://rh-aluextrusions.com/1-2-aluminum-hollows-aluminum-round-tubes.html

With the experience of producing over 100 thousands aluminum extrusions, RH Group houses an extensive standard shapes die bank for mass production, thus to lower tooling costs. Being an aluminum extrusion manufacturer, RH Group can produce aluminum alloy rods in 2000, 3000, 4000,5000, 6000 and 7000 series, and deliver customized surface treatment and finishing service for our aluminum extrusions used in different applications, such as architecture, industry, electronics.

Quantity of dies: 176 sets
CCD (circumscribing circle diameter): ≤210mm

Specifications

No.	Part Number	OD mm	ID mm	Wall Thickness mm	Weight kg/m
1	Round Tube-RH148-164	72	60	6	3.42
2	Round Tube-RH2021-013	54.5	37	8.75	3.46
3	Round Tube-RH245-261	47	42.6	2.2	0.85
4	Round Tube-RH2021-015	23	9	7	0.97
5	Round Tube-RH2041-004	66.4	61.8	2.3	1.27
6	Round Tube-RH2021-016	56	43	6.5	2.78
7	Round Tube-RH2021-017	44	30	7	2.24
8	Round Tube-RH2021-018	54	38.4	7.8	3.11
9	Round Tube-RH1974-167	50.3	40	5.15	2.01
10	Round Tube-RH1648-075	32.3	29.95	1.17	0.32
Customized aluminum round tubes are available
