Application

3003 aluminum is commonly used in sheet metal applications such as HVAC, hinges, condensers, radiators, heat exchangers, evaporators, heat shields, gutters, downspouts, and roofing and siding, fuel tanks, cabinets, trucks and trailers, chemical equipment, kitchen ware, architectural and decorative materials, etc.

Aluminum alloy state, size and mechanical properties

Alloy	Temper	Thickness (mm)	Tensile strength (Mpa)		Elongation (%)
			Chinese standard	Value
3003	O	＞0.2-0.5	95-140	95-135	≥20
		＞0.5-1.0			≥35
		＞1.0-4.5			≥35
	H22	＞0.2-0.5	120-160	130-160	≥15
		＞0.5-1.0			≥18
		＞1.0-4.5			≥20
	H24	＞0.2-0.5	145-195	150-180	≥12
		＞0.5-1.0			≥12
		＞1.0-4.5			≥15
	H26	＞0.2-0.5	170-210	165-205	≥3
		＞0.5-1.0			≥5
		＞1.0-4.5			≥7
	H18	＞0.2-0.5	≥190	≥185	≥1
		＞0.5-1.0			≥3
		＞1.0-4.5			≥4
