Applicable Materials
The CMA1810-FET-C equipment is applicable for materials like cotton, fabric, leather, paper and other textile fabrics.

Cutting System

Model Laser power (W) Laser head Conveyer Working area
(mm)
Overall dimension
(mm)
Weight (Kg) Speed (m/min) Supply voltage Working environment
CMA1810-FET-C 60~130 Double Epsilon-type conveyer table 1700×950 2460×2163×1112 515Kg 0~24 AC220V±10% Temp: 5~ 40°C, Humidity:5~80%. No condensate water, no dust or less dust.

Laser Processing Examples:

  • clothing accessories laser cutting
  • Garment, accessories and cloth laser cutting
  • Hair accessories laser cutting
  • Laser cutting of T-shirt collar
  • shoe material laser cutting
  • Sticker laser cutting
  • Vamp laser hollow-out

Product Feature
1. A double head electric mutual shift achieves automatic separated head processing.
2. Automatic material feeding system: the double laser head achieves automatic space adjustments in order to save manpower and adjustment time.
3. This laser cutter is equipped with a material cutting system, which can make the best use of expensive materials. Compared to traditional mechanical cutters, it can significantly save on material costs.
4. When it cuts odd row, one cutter head can automatically stop output laser beams in order to avoid damaging already cut fabric.
