600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A
600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A

600×600mm High Precision CO2 Laser Cutting Machine, CMA0606D-G-A

Cutting System

Model Laser power
(W)
Laser head Working area
(mm)
Overall dimension
(mm)
Weight
(Kg)
Repeated positioning
accuracy
(mm)
Speed
(m/min)
Supply voltage Working environment
CMA0606D-G-A 55~100 Single 600×600 2000×1680×200 1700 ≤±0.01 0~6 Three phases
380V/50Hz/60Hz
Temp: 5~40°C, Humidity: 5~80%. No condensate water, no dust or less dust.

Laser Processing Examples:

  • Board base material high precison laser cutting
  • composite material high precison laser cutting
  • Electronic paper high precison laser cutting
  • Electronic paper watch high precison laser cutting
  • PCB high precision laser cutting
  • Touch display screen high precision laser cutting
  • Touch screen high precison laser cutting
  • Touch screen

Product Feature
1. The laser cutting system adopts casting lathe bed, which brings higher accuracy and stability. It can effectively eliminate vibration during high-speed cutting.
2. Double ball screw and dual motor driving system have high-speed arc cutting capabilities which can effectively improve production efficiency.
3. Automatic lubrication system makes transmission parts maintenance free. It can cut corrosive materials.
4. It is equipped with Germany imported PA CNC system with original packaging, which has pattern layout design and sharp corner smoothened functions, so as to realize high-speed punching.
5. Working power and frequency changes with the set cutting speed, which can effectively reduce burrs during cutting.
