ST3090EV Electric Skid Steer Loader
Request a Quote
Wheeled electric skid loader delivering up to 8 hours of operation on a single charge
- Bucket capacity
0.5m³ - Operating weight
3500kg - Travel speed
14km/h - Rated load
1000kg
- Extended battery life, providing 6-8 hours of continuous operation per charge for efficient daily use
- High-efficiency power system combining 4×12kW drive motors with a 30kW hydraulic system for smooth, responsive performance
- Rated load of 1000 kg and 0.5 m³ bucket capacity, offering excellent loading and material-handling capability in compact spaces
Specifications
| A | Overall height | 4270mm |
| B | Bucket pin height at maximum lift | 3265mm |
| C | Height to top of cab | 2007mm |
| D | Height to level bucket | 3090mm |
| E | Overall length (without bucket) | 2571mm |
| F | Overall length (with bucket) | 3498mm |
| G | Max. dumping angle | 35° |
| H | Dumping height | 2551mm |
| J | Dumping reach | 603mm |
| k | Back angle on ground | 30° |
| L | Back angle at lifting height | 103° |
| M | Wheelbase | 1020mm |
| P | Ground clearance | 185mm |
| Q | Departure angle | 22° |
| R | Turning radius from center (no bucket) | 1235mm |
| S | Turning radius from center | 2110mm |
| T | Turning radius from rear tail | 1643mm |
| U | Bumper overhang behind rear axle | 1080mm |
| V | Width | 1469mm |
| W | Overall width (tires) | 1740mm |
| X | Overall width (bucket) | 1800mm |
| Y | Alarm light height | 190mm |
Technical Parameters
| Bucket capacity | 0.5m³ |
| Operating weight | 3500kg |
| Travel speed | 14km/h |
| Rated load | 1000kg |
| Tire type | 12-16.5 |
| Power Battery | |
| Battery type | Lithium ion |
| Battery voltage | 380V |
| Battery capacity | 53.6kWh |
| Reference running time | 6-8h |
| Driving System | |
| Motor type | Permanent magnet synchronous motor |
| Motor power | 4×12kW |
| Hydraulic System | |
| Motor type | Permanent magnet synchronous motor |
| Motor power | 30kW |
| Hydraulic flow | 70l/min |
| Hydraulic pressure | 215bar |
Note:
With ongoing technological advancements, product specifications and configurations are subject to change without prior notice. In case of any uncertainty, the final confirmation provided by our international trade sales team shall prevail.
Optional attachment
- Standard bucket
- Deep bucket
- Screening bucket
- Quick coupler
- Pallet forks
- Auger
- Snow plow blade
- Log grapple
- Round bale handler
- Square bale handler
- Flail mower
- Lifting boom / Crane Attachment
