G8 Alloy Steel Shackles

Request a Quote

View All: http://shenli-rigging.com/4-2-g8-alloy-steel-shackles.html

Features
● All the shackles and bolts are forged by special alloy steel with high intensity and high toughness, and then they are heat treated;
● We should carry out strict sampling and breakage testing for each batch of products;
● We should carry out 100% magnetic powder flaw detection;
● The applicable temperature range: -40℃-200℃.
● It can not be used beyond the working load limit.

SLR756-G8 BOLT TYPE ALLOY BOW SHACKLE

Parameters (Unit: mm)

Item Code	Weight/lbs	Working Load Limit/t	Breaking Load/t	A±1.5	C±1.5	D±1	L±3	N	L1+3	B
SLR-756-5/16	0.22	1.2	6	13.5	21.3	8	53	9.5	50.5	8.4
SLR-756-3/8	0.33	1.6	8	16.8	25.9	9.7	63.2	11	62	10.8
SLR-756-7/16	0.49	2.5	12.5	19	29.5	11.2	74	13	70	12.8
SLR-756-1/2	1.01	33.3	16.5	20.6	33.3	12.7	83.3	16	79.5	14.8
SLR-756-5/8	1.60	5	25	27	42.9	17.5	106.4	19	101.5	18
SLR-756-3/4	2.42	7	35	32	20.8	20.6	126.2	22	117.5	19.4
SLR-756-7/8	3.95	9.5	47.5	36.6	57.9	24.6	148	25	136	21.5
SLR-756-1	5.66	12.5	62.5	43	68.3	27	166.6	28	153.5	23.8
SLR-756-1-1/8	8.27	15	75	46	74	31.75	190	32	171.5	25.6
SLR-756-1-1/4	11.71	18	90	51.6	82.5	35	210	35	192	31
SLR-756-1-3/8	15.83	21	105	57	92	36	232.7	38	202	33.4
SLR-756-1-1/2	20.8	30	150	60.5	98	41	254	42	222	34
SLR-756-1-3/4	33.91	40	200	73.2	126	57.2	313.7	51	278	38
SLR-756-2	52.25	55	275	82.5	146	61	347.5	57	307	45

SLR757-G8 BOLT TYPE ALLOY BOW SHACKL

Parameters (Unit: mm)

Item Code	Weight/lbs	Working Load Limit/t	Breaking Load/t	A±1.5	D±1	N	L±3	L1+3	B
SLR-757-5/16	0.23	1.2	6	13.5	8	9.5	48.5	50.5	8.4
SLR-757-3/8	0.33	1.6	8	16.8	9.7	11	58.4	62	10.8
SLR-757-7/16	0.49	2.5	12.5	19	11.2	13	67.6	70	12.8
SLR-757-1/2	0.75	3.3	16.5	20.6	12.7	16	77	79.5	14.8
SLR-757-5/8	1.47	5	25	27	17.5	19	97.3	101.5	18
SLR-757-3/4	2.52	7	35	32	20.6	22	116.6	117.5	19.4
SLR-757-7/8	3.85	9.5	47.5	36.6	24.6	25	135.4	136	21.5
SLR-757-1	5.55	12.5	62.5	43	27	28	152.4	153.5	23.8
SLR-757-1-1/8	7.60	15	75	46	31.8	32	172.4	171.5	25.6
SLR-757-1-1/4	10.81	18	90	51.6	35	35	190.5	192	31
SLR-757-1-3/8	13.75	21	105	57	35	38	206.8	202	33.4
SLR-757-1-1/2	18.5	30	150	60.5	41	42	230.1	222	34
SLR-757-1-3/4	31.4	40	200	73.2	53.8	51	279	278	38
SLR-757-2	46.75	55	275	82.5	61	57	324.6	307	45

Normal mark: G8 5/8 WLL5T CE SLR +BATCH NUMBER

SLR758-G8 BOLT TYPE ALLOY BOW SHACKL

Parameters (Unit: mm)

Item Code	Weight/lbs	Working Load Limit/t	Breaking Load/t	A±1.5	C±1.5	D±1	N	L±3
SLR-758-5/16	0.19	1.2	6	13.5	21.3	8	9.5	53
SLR-758-3/8	0.31	1.6	8	16.8	25.9	9.7	11	63.2
SLR-758-7/16	0.38	2.5	12.5	19	29.5	11.2	13	74
SLR-758-1/2	0.73	3.3	16.5	20.6	33.3	12.7	16	83.3
SLR-758-5/8	1.37	5	25	27	42.9	17.5	19	106.4
SLR-758-3/4	2.36	7	35	32	20.8	20.6	22	126.2
SLR-758-7/8	3.62	9.5	47.5	36.6	57.9	24.6	25	148
SLR-758-1	5.03	12.5	62.5	43	68.3	27	28	166.6
SLR-758-1-1/8	7.41	15	75	46	74	31.75	32	190
SLR-758-1-1/4	9.50	18	90	51.6	82.5	35	35	210
SLR-758-1-3/8	13.53	21	105	57	92	36	38	232.7
SLR-758-1-1/2	17.20	30	150	60.5	98	41	42	254
SLR-758-1-3/4	27.78	40	200	73.2	126	57.2	51	313.7
SLR-758-2	45.00	55	275	82.5	146	61	57	347.5

SLR759-G8 BOLT TYPE ALLOY BOW SHACKLE

Parameters (Unit: mm)

Item Code	Weight/lbs	Working Load Limit/t	Breaking Load/t	A±1.5	D±1	L±3	N
SLR-759-5/16	0.17	1.2	6	13.5	8	48.5	9.5
SLR-759-3/8	0.28	1.6	8	16.8	9.7	58.4	11
SLR-759-7/16	0.43	2.5	12.5	19	11.2	67.6	13
SLR-759-1/2	0.59	3.3	16.5	20.6	12.7	77	16
SLR-759-5/8	1.25	5	25	27	17.5	97.3	19
SLR-759-3/4	2.63	7	35	32	20.6	116.6	22
SLR-759-7/8	3.16	9.5	47.5	36.6	24.6	135.4	25
SLR-759-1	4.75	12.5	62.5	43	27	152.4	28
SLR-759-1-1/8	6.75	15	75	46	31.8	172.4	32
SLR-759-1-1/4	9.06	18	90	51.6	35	190.5	35
SLR-759-1-3/8	11.63	21	105	57	35	206.8	38
SLR-759-1-1/2	15.95	30	150	60.5	41	230.1	42
SLR-759-1-3/4	26.75	40	200	73.2	53.8	279	51
SLR-759-2	42.31	55	275	82.5	61	324.6	57
