Long Run IP65 SMD2835 Warm LED Strip Light, 10m/20m/50m/100m
Request a Quote
Key Features
- Ambient Temperature:-20℃ to 45℃
- Voltage: DC24V
- Length/Reel(M/ft): 10m/32.8ft, 20m/65.4ft, 50m/164ft, 100m/328ft
- Built-in Audion (as known as a triode) on constant current circuit improves stability of working current and output brightness
- Cascade design guarantees the consistent brightness of one complete roll of LED strip light. All LED Chips are independently produced in the LEDMY factory, which allows for the consistent brightness among different batch products. Ideal for large-scale projects
- 7 LEDs per segment deliver better lighting effects
- No need for welding PCB components. Each LED segment can be cut and reconnected with a cut unit length of 100mm
- Single-ended power input LED, serial connection length up to 100m. Easier to install and use.
- Premium silicone tubes bring waterproof protection, better cooling performance and higher flexibility for easier bending and twisting
Specification
| Model | Length | Led Qty | Power | Lumens per feet |
| FP15W-P5-G1 28AS9x 24VT70S W10L10 NILED | 10M | 70LEDs/M | 15/M 4.6W/ft | 1420-1550lm/M 433-472lm/ft |
| FP10W-P5-G1 28AS9x 24VT70S W10L20 NILED | 20M | 70LEDs/M | 10W/M 3.05W/ft | 1000-1110lm/M 305-338lm/ft |
| FP05W-P5-G1 28AS9x 24VT70S W10L40 NILED | 40M | 70LEDs/M | 4.8W/M 1.46W/ft | 500-560lm/M 152-171lm/ft |
| FP02W-P5-G1 28AS9x 24VT70S W10L100 NILED | 100M | 70LEDs/M | 2W/M 0.61W/ft | 200-280lm/M 61-85lm/ft |
- Applications
Accessories
- FPC Connector
- Non-waterproof LED Power Supply, Compact Series
- LED Controllers
Projects
- Shenzhen Shekou Sea World
- Bangkok Center Viaduct, Thailand
- Wong Tai Sin, Kowloon, Hongkong
