High Speed Net Knitting Machine
Request a Quote
GE2395 Raschel Machine
Raschel warp knitting machine for producing PE braided nets, architectural nets and road safety nets
Processing materials
Weaving PE plastic filaments to make various mesh fabrics.
Applications
PE braided nets, architectural nets and road safety nets
Features
- The net warp knitting machine uses oil-immersed cam or crank connecting rod drive mechanism.
- This Raschel machine comes with a compound needle to knock over from the bar, ensuring faster production speeds.
- This net warp knitting machine adopts Raschel knitting elements.
- The Raschel warp knitting machine supports electronic yarn let-off, electronic take-up, and electronic batching functions.
Specifications
- Needle type Compound needle
- Gauge E6, E9, E18
- Number of bars 2-4 bars
- Working width 186" (customizable)
- Max. speed 800 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 2200×2300×1950 | 5.06 | 3000 | 7.5 | |
| 5200×2700×1950 | 14 | 7000 | 14.75 | |
| 6200×2700×1950 | 16.74 | 8000 | 14.75 | |
| 8450×2700×1950 | 53.46 | 15000 | 18.25 |
