Net Weight Filling Machine (5L-30L)
Request a Quote
Suitable for Filling: lubricant oil / car oil / motor oil / coolant liquid / engine oil /brake oil / edible cooking oil / agrochemical / fertilizer / pesticide / chemical.
Filling Range: 5L -30L
The weighing filling machine is used for filling liquid in a range of 5 to 30kg. It features a weight feedback system under each fill head to ensure the filling accuracy.
Features
- The weighing filling machine is made of 304 stainless steel.
- The machine uses a PLC with touchscreen as its control system.
- The diving nozzle is designed to prevent bubble formation.
- Each fill head has a weight feedback system underneath to ensure the filling precision.
- The machine is easy to take apart and clean for routine maintenance.
- An alarm will sound in the event of machine failure.
- Flexible operation: suitable for filling bottles in a range of 5 to 30kg in capacity.
Specifications
| Model | ||
| Dimension | 2535*1410*2085mm | 3000×1700×2300mm |
| Filling head | 4 | 6 |
| Capacity（5L） | 400B/H | 550 B/H |
| Capacity（20L） | 220B/H | 350 B/H |
| Power | 1.5KW | 2KW |
| Suitable bottle | Length:160-360mm width:100-300mm height:250-500mm | |
| Filling System | Load Cell Net Weight Filling System | |
| Barrel neck diameter | ≥Φ40mm | |
| Filling error | ≦±0.5%F.S | |
| Filling range | 5kg-30kg（Liters） | |
| Air pressure | 0.6Mpa-0.8Mpa | |
| Power supply | 220V, 50HZ | 220V, 50HZ |
