CMS 25kVA UPS, Scalable to 200kVA, 400V Manufacturer

CMS 25kVA UPS, Scalable to 200kVA, 400V

Request a Quote

View All: http://siconelectric.com/1-3-2-cms-25kva-ups-scalable-to-200kva-400v.html

Sicon developed the CMS rackmount UPS system to fit in narrow spaces in server rooms or other similar situations. The rack-mounted UPS system can be embedded into standard 19 inch cabinets and integrated into small or medium-sized server rooms or specific cold/hot aisle server rooms.

CMS/A-200 Power units

Input/output wires
200kVA STS (static switch)
Maintenance bypass line
System monitoring (above eye sight)
Maximum power of 200kVA/180kW
3-phase input/output power connection
400/230VAC, 50Hz
SNMP port
Applies to any 19 inch 600*800 (W*H) cabinets
Height: 16U (1U=44.45mm)

CMS/A-100 Power units

Input/output wires
100kVA STS (Static Switch)
Maintenance bypass line
System monitoring (above eye sight)
Maximum power of 100kVA/90kW
3-phase input/output power connection
400/230VAC, 50Hz
SNMP port
Applies to any 19 inch 600*800 (W*H) cabinet
Height: 9U

CM/A100F Power module set

Maximum of four 25kVA/22.5kW UPS modules
Maximum power of 100kVA
CMS/A-100 power unit could combine with 1 CM/A100F power module set
CMS/A-200 power unit could combine with 2 CM/A100F power module sets
3-phase input/output power connection
400/230VAC, 50Hz
Applies to any 19 inch 600*800 (W*H) cabinet
Power module set height: 12U

CM/A50F Power module set

Maximum of two 25kVA/22.5kW UPS modules
Maximum power of 50kVA
CMS/A-100 power unit could combine with 2 CM/A50F power module sets
3-phase input/output power connection
400/230VAC, 50Hz
Applies to any 19inch 600*800 (W*H) cabinet
Power module set height: 6U

UPS System Technical Parameters

Module

Module model	CM/A25
Module power	25KVA
Power connection	3/1, 3/3, 1/1, 1/3 phase
Module dimension (H×W×D)mm	133×482×465
Weight (kg)	Approximate 20 kg
Module charging	Each module provides 6kW charging power
Input power factor	≥0.99
Overload ability	135%
Maximum heat dissipation power	1187W
THDI (%)	≤3%

Mains Input

Input mode	3-phase N E, 1-phase N E
Input voltage	380V/220V±20%、400V/230V±20%、415V/240V±20%
Input frequency	50Hz±10%、60Hz±10%
Power woke-in (Sec.)	60sec
THDI（%）	＜3%
Input PF	≥0.99

Bypass Input

Input voltage	380V/220V±20%、400V/230V±20%、415V/240V±20%
Input frequency	50Hz±4%, 60Hz±4%
Range of Frequency Synchro	50Hz±4%, 60Hz±4%

DC Input

Rated Input voltage	±384VDC
Input voltage tolerance	±345V～±440V DC

Battery charging

Charging current limited	yes
Charging ability	10 hours (2 hours back up)
Stability of charging voltage	±1%

AC output

UPS power factor	0.9
Output voltage	220V/230V
Output frequency	50Hz±4%, 50Hz±0.2%
Output frequency	60Hz±4%,60Hz±0.2%
Output voltage stability	380V/220V±1% (Static); 380V/220V±2%(load 0~100% change)
	400V/230V±1% (Static); 400V/230V±2%(load 0~100% change)
	415V/240V±1% (Static); 415V/240V±2%(load 0~100% change)
Output voltage recovering time	＜20ms(load 0~100% change)
Overload ability	Operate 10mins with 125% load
Transfer from mains to battery supply	0ms
Transfer from bypass to inverter supply	< 10ms
Peak factor	3:01
Waveform distortion	≤1% ( linear load ), ≤3%( non-linear load )
Overall efficiency	≥95% (AC~AC), ≥98% (DC~AC)
Load share precision	≤5%

Operation environment

Ambient temperature	-25℃～60℃
Operating temperature	-5℃～40℃
Maximum operation altitude	≤1500m
Relative humidity	≤95% non-cadency
Protection degree	IP30
Cooling	Air cooling
Applicable safety standards	EN62040-1-1:2003 IEC60950-1:2001
Electromagnetic compatibility	EN62040-2:2006
Acoustic noise	≤55dB

Others

Cabinet size（W×D×H）mm	6008002000
Weight(kg)	240
Cabinet	Standard 19 inch cabinet
Monitor management system	UPSupervisor
RS232, RS485 and 8 try contact, TCP/IP adapter, SNMP(optional)	Standard
SNMP	Optional
Display	LCD/LED

Advantages

All individual modules in CMS rackmount UPS system support hot swapping and fault isolation functions, meaning the module will quit the system automatically whenever malfunction is detected. In the meantime, all power modules have automatic load sharing to ensure a reasonable system redundancy and fault-tolerance. So that our CMS UPS system always meets TIER1-4 standards when applying to different sized data centers or server rooms.
UPS system supports hot swapping function (add or remove when the system is running), you can add or remove power modules according to specific load requirements.
The UPS system is composed of multiple 25kVA power modules, and you can select appropriate module quantities according to your specific load requirements.
The system satisfies single phase or three phase input/output mode.
