80° Dies, H=86mm, Amada Press Brake Tooling
Request a Quote
| F 31.021(F=750KN/m Max) | |
| Radius | 2mm |
| Length | Weight |
| Width | 34mm |
| Material Thickness | 2.0mm-4.0mm |
| Standard Length100mm | 2.44KG |
| Standard Length500mm | 12.20KG |
| F 31.032.10(F=1200KN/m Max) | |
| Radius | 2mm |
| Length | Weight |
| Width | 40mm |
| Material Thickness | 3.5mm-6.0mm |
| Standard Length100mm | 2.80KG |
| Standard Length500mm | 14.00KG |
