Heat Shrink Fluoropolymer Tubing
Request a Quote
Model: CYG-FKM
Material: Irradiated cross-linked modified fluoroelastomer
Shrink ratio: 2:1
Application
This fluoropolymer heat shrink tubing is used for electronic components at elevated temperatures and in oily environments for insulation protection of resistors and capacitors, and for mechanical protection of various metal wirings, such as insulation of wire ends and terminals.
Standard: AS23053/13
Size| Size (inch) | Inside diameter | Wall thickness after recovery (mm) | Standard length (m/spool) | |
| Minimum expanded as supplied (mm) | Maximum after recovery (mm) | |||
| 1/8 | 3.2 | 1.6 | 0.76 | 50 |
| 3/16 | 4.8 | 2.4 | 0.89 | 50 |
| 1/4 | 6.4 | 3.2 | 0.89 | 50 |
| 3/8 | 9.5 | 4.7 | 1.02 | 50 |
| 1/2 | 12.7 | 6.4 | 1.22 | 30 |
| 5/8 | 15.9 | 7.9 | 1.40 | 30 |
| 3/4 | 19.0 | 9.5 | 1.45 | 30 |
| 7/8 | 22.2 | 11.1 | 1.53 | 30 |
| 1 | 25.4 | 12.7 | 1.78 | 30 |
| 1-1/4 | 31.8 | 15.9 | 1.91 | 30 |
| 1-1/2 | 38.1 | 19.1 | 2.41 | 15 |
| 2 | 51.8 | 25.4 | 2.79 | 1 |
| Item | CB-KFM fluoroelastomer shrinkable tubing | Silicone rubber shrinkable tubing |
| Operating temperature (℃) | -55℃~ 200℃ | -60℃~ 200℃ |
| Mechanics | Good | Poor |
| Acid and alkali resistance | Good | Poor |
| Oil resistance | Excellent | Normal |
| Flammability | Good Self-Flammability | Flammable, and bad self-flammability |
| Abrasion resistance | Normal | Poor |
| Sealing | Good | Poor |
| Insulation | Normal | Good |
| Water proof | Good | Normal |
- This heat shrink tubing is oil resistant, heat resistant, flame retardant, acid resistant, alkali resistant and flexible. Made from fluoropolymer, it features a high temperature resistance of up to 200℃. The heat shrink tubing contains an organic filler, allowing it to offer long-term service in applications such as automotive diesel. After the irradiation cross link process, the recombination of molecular structures will flexibly attach and improve the plasticity. This heat shrink tubing is suitable for coating irregular shapes in harsh environments.
- The operating temperature of this heat shrink tubing is -40℃~200℃.
- The shrink temperature of this heat shrink tubing is 175℃.
- The standard color of this heat shrink tubing is black.
