JX-260R1C Flexo Printing Press
Request a Quote
JIN XIANG’s JX-260R1C cellophane label letterpress machine offers printing on cellophane labels such as tape, self-adhesive labels, daily use chemical labels, food labels, electronic labels, bar code labels and more for informative packaging purposes.
The following shows a single-color letterpress machine we customized for our customers with a web width of 260mm, making it ideal for printing cellophane labels. We will change equipment configurations or customize new equipment to meet customer requirements for printing effects and capacity.
Technical specs
| Model | JX-260R1C |
| Gearing | 1/8" |
| Max. Web width | 260mm |
| Max. Print width | 250mm |
| Max. unwind width | 800mm |
| Max. Rewind width | 800mm |
| Max. Print length | 650mm |
| Min. Print length | 190.5mm |
| Print speed | 100m/min |
| Machine net weight | 1500KG |
| Machine gross weight | 2000KG |
| Power of main engine | 2KW 380V |
| Motor power of ink dispenser (6pcs) | 420W |
| UV dryer | 5KW |
| Machine size (W×L×H) | 1.2×2.5×1.6m |
Standard configuration
- Printing station (1 set)
- Plate cylinder (1 set, optional size)
- UV curing system(1 set)
- Tools (1 set)
- Printing plate mounter (1 set)
- Flexo plate proofer (1 set)
- Splicing table (1 sets)
- Corona treatment unit (1 set)
- Unwinder and rewinder (1 set respectively)
- Protective layer laminator (1 set)
Optional equipment
- Cold foil unit
- Gravure printing unit
- Round screen printing unit
- Slitting and sheeting system
- Static observation system
- Cooling system
- Electrostatic eliminator
- Lamination unit and cross over unit for multi layer label production
