Laser Die Cutting Machine (Model LD-360 Laser Die Cutter)
Request a Quote
Features
- Laser die cutting uses a high-speed laser to cut through various substrates in an efficient and non-contact manner.
- Computer-controlled laser die cutting machine provides high precision and reduced cost without manual operation.
- It’s integrated with the funcions of laminating, die cutting, waste removal, sheeting, rewinding, slitting, etc.
Technical Specifications
| Model | LD-360 |
| Machine Type | Roll to roll |
| Web Width | 50-380mm |
| Die Cutting Range | Width 360mm, length can be spliced |
| Laser Power | 200W |
| Die Cutting Method | Color code positioning laser die cutting |
| Function Selection | Punching, lamination, slitting |
| File Format | PLT, PDF, JPG |
| Applicable Materials | Self-adhesive labels, printed labels, paper, film, etc. |
| Voltage | AC220V |
| Total Power | 5.5kW |
| Working Environment | Humidity:40%-70% Temperature:20-30 degree |
| Weight | 1800kgs |
