Cutter Heads
Request a Quote
Type
Planer cutterhead, serrated cutterhead, profile cutterhead
Planer cutterhead
Planer cutterhead has planer knives. Knife is made from high speed steel or alloy. Body is made from professional quality steel and aluminum, with wide application.
| D (mm) | H | Bore | Z | |
| Without knife | With knife | |||
| 122 | 125 | 40 | 40 | 4 |
| 122 | 125 | 60 | 40 | 4 |
| 122 | 125 | 80 | 40 | 4 |
| 122 | 125 | 100 | 40 | 4 |
| 122 | 125 | 120 | 40 | 4 |
Serrated cutterhead
Comes with corrugated knives. Knives are made from high speed steel or alloy. The knives need counterweight for installation.
| D (mm) | H | Bore | Z | |
| Without knife | With knife | |||
| 122 | 125 | 40 | 40 | 4 |
| 122 | 125 | 60 | 40 | 4 |
| 122 | 125 | 80 | 40 | 4 |
| 122 | 125 | 100 | 40 | 4 |
| 122 | 125 | 120 | 40 | 4 |
Profile cutterhead
Comes with profile knives. Body is made from aluminum and steel. Customization is available following customer needs for different colors.
| D (mm) | H | Bore | |
| 68 | 40 | 20 | |
| 78 | 40 | 30 | |
| 90 | 40 | 30 | |
| 120 | 40 | 50 |
| D (mm) | H | Bore | |
| 90 | 40 | 30 | |
| 120 | 40 | 50 |
| D (mm) | H | Bore | |
| 100 | 40 | 30 | |
| 120 | 40 | 50 |
