Applications
The PX fine crusher is newly developed for secondary or tertiary crushing of the ore, rock, and other material with the compressive strength less than 320MPa. The rock crusher is extensively used in the industry such as mining, metallurgy, building material, mineral separation, sand making, ceramics, and so on.

Features
1. The fine crusher is scientifically designed for convenient adjustment and stable and reliable operation.
2. The outstanding size reduction ratio and the fine granularity of the discharged material are conducive to the high crushing efficiency of the fine crusher.
3. Unique adjusting mechanism for the fine crushing equipment enables high use ratio of the hammerhead and the sieve plate.
4. Requiring less maintenance, the high-strength fine crusher is capable of saving 20% operating cost for the users.

Techncial Paramaeters of Fine Crusher
Model Inlet Size (mm) Max. Feed Material Side Length (mm) Adjustable Size of Outlet (mm) Granularity of Discharged Material (mm) Handling Capacity (t/h) Motor Power (kW)
PX0808 800 x 300 160 5-20 <5 30-40 55
PX1010 1000 x 350 180 5-20 <5 40-60 90
PX1212 1200 x 450 180 5-20 <5 80-120 132
PX1414 1500 x 500 190 5-20 <5 120-180 200
PX1616 1600 x 550 200 5-20 <5 170-210 250
PX1818 1800 x 700 200 5-20 <5 250-270 315
