Self-Moving Traction Machine
Request a Quote
This ZZC350 type self-moving traction machine can be used to spread the optical power ground wire abbreviated as OPGW. Also, it is able to replace the old conductor.
Technical Parameters
| Item Number | 20121 |
| Diameter Range of Pulley (mm) | Φ9-26 |
| Maximum Angle of Climb (°) | 31 |
| Type of Gasoline Engine Generator | YK950/650W |
| Type of Driving Motor | 100YYJ140-3 (140W) |
| Remote Control Linear Distance (m) | 300-500 |
| Overall Dimension (mm) | 477× 488× 763 |
| Running Speed (m/min) | 17 |
| Horizontal Pulling Force (N) | 350 |
| Weight (kg) | 46.5 |
