The U7 model small linear actuator is a small-sized industrial linear actuator, which is applicable for Christmas trees, vehicle trunks, and industrial appliances. Its longest stroke is more than 1m, and the smallest installation distance is 108mm + stroke. These linear actuators are small, waterproof and easy to install.
The inner tube, outer tube and gear box are made of aluminum alloy, and the gear is manufactured using a powder metallurgy process.
Parameters- Voltage: 12/24V DC
- Max load capacity: 2000N (push)
- No-load velocity: 5~60mm/s
- Full-load velocity: 4~45mm/s
- Duty cycle：25%
- Waterproof class：IP65
- Noise level: less than 65dB
- Temperature：-40℃ ~ +70℃
- The compact structure of this linear actuator ensures it is small and saves space.
- The shell features an outstanding corrosion resistance.
- This product is waterproof, dustproof, and has an excellent salt spray resistance, making the actuator ideal for harsh environments.
- It uses a metal gearbox and features a long service life.
- It is designed with a stable, durable structure.
- The linear actuator features a high positioning accuracy and short response time.
- It requires minimal maintenance and features a low energy consumption.
- This linear actuator is widely used in industrial automation equipment, electric window opener, sweeper, scissor lift platforms and other motorized equipment.
Curve graph ① Load VS Curent; ② Current (A); ③ Load (N); ④ Load VS Speed; ⑤ Speed (mm/s)
Code of Parameters| code | Rated laod (N) | Rated current(A) | Rated speed (mm/s) | ||
| Push | Pull | No-load(32VDC) | Full-load(24VDC) | ||
| Standard motor (5200RPM) | |||||
| A | 2000 | 2000 | 2.2 | 7 | 6 |
| B | 1500 | 1500 | 2.2 | 9.3 | 8 |
| C | 1000 | 1000 | 2.2 | 14 | 12 |
| D | 500 | 500 | 2.2 | 28 | 24 |
| E | 250 | 250 | 2.2 | 43 | 36 |
| High Speed Motor(6600RPM) | |||||
| F | 2000 | 2000 | 2.8 | 5.8 | 7.5 |
| G | 1500 | 1500 | 2.8 | 9.3 | 10.3 |
| H | 1000 | 1000 | 2.8 | 13.2 | 15 |
| I | 500 | 500 | 2.8 | 26.4 | 10.8 |
| J | 250 | 250 | 2.8 | 20.2 | 46 |
Comment: when the voltage change from 24V to 12V, the current will be doubled.
Customization parameter1=12V
2=24V(standard)
3=36V
4=48V1=Tined leads
2= 01 Pin
3=Din 6pin
C=customization
1=Φ6.4mm
2=Φ8mm
3=Φ10mm
4=Φ6.4mm，slot 6mm
5= Φ8mm，slot 6mm
6=Φ10mm，slot6mm
C=customization1=holeΦ6.4mm
2=holeΦ8mm
3=clevis, slot 5.2mm, hole Φ6.4mm
4=clevis, slot 4.2mm, hole Φ6.4mm
5=clevis, slot 4.2mm, hole Φ8mm
6=rod type, hole Φ6mm
7=rod type, hole Φ8mm
C=customization
1=90°
2=0°／180°1=no signal
2=analog signal from potentiometer
3=pulse signal from single Hall sensor
4=pulse signal from Dual Hall sensor
1=straight wire,0.5m
2=straight wire,1m
3=straight wire,1.5m
4=straight wire,2m
5=straight wire,3m
C=customization1=built-in limit switch off to stop
2=built-in limit switches off to output signal, exterior switches off to stop
3=built-in limit switches close to output signal, exterior switches off to stop
C=customization
