Multi-Head Embroidery Machine, Flat Embroidery, 1000rpm

Features

Maximum flat embroidery speed of 1000rpm.
Ultra-low noise and ultra-low vibration during high speed operation.
Service life up to 10 years.
The semi-static trimming system is equipped with a stepping motor for a 100% trimming pass rate and an adjustable end thread length.
The entire structure is reinforced with high precision dowel pins, while the head interval and X and Y axis location detection accuracy is 0.05mm.
The servo drive embroidery hoop system features a high torque and light weight, meeting the needs for high speed and exceptional quality embroidery needs.

Applications

This series embroidery machine is ideal for working on a variety of clothing, home textiles, and embroidery artwork, as well as working with thick and thin fabrics, it an economically choice for your business

Details

Specifications

Model	Needles	Heads	Head interval (mm)	X travel (mm)	Y travel (mm)	L(mm)	W(mm)
HE-A912/300-600-900	9	12	300	600	900	5320	2350
HE-A918/300-600-900	9	18	300	600	900	7060	2350
HE-A924/400-800-900	9	24	400	800	900	11760	2350
HE -A1515-900-1000-1350	9	30	300	600	900	11100	2350

Optional

Multi sequin device
Cording device
Seed beads device
Taping beads device
Hot cutting device
Fiber laser
Boring device
