LPS20 Priority Valve
Request a Quote
- Priority valve supplies oil to steering system and hydraulics by just one pump.
- Low pressure drop at high flow rate.
- Control valve can be equipped with load sensing steering unit and variable pump to save energy.
- Hydraulic valve can be manufactured with sequence valve, diverter valve, relief valve and other valves.
Applications
- Wheel loader
- Forklift
- Excavator/loader
- Agricultural machinery
- Material handling machinery
- Compactor
- Forestry machinery
Parameters
| Rated pressure (MPa) | 25 |
| Rated flow (L/min) | 160 |
| Deferential control pressure (MPa) | 1 |
| Hydraulic oil | Mineral oil (HL, HLP) in accordance with DIN 51 524 |
| Fluid temperature range (℃) | －20-100 |
| Viscosity range (mm2/s) | 10-380 |
| Fluid cleanliness | Not lower than GB/T 14039-2002 level 19/16 or NAS 1638 level 10 |
| Weight (Kg) | 5.5 |
Professional supplier engaged in the R&D, manufacturing, and sales of various hydraulic components
Annual production capacity of 250,000 sets of hydraulic components
Over 30 series and over 200 varieties and specifications to meet the specific needs of our clients
