V Head Pipe Stand, 1107 series
Request a Quote
- Heavy type V head: Pipe stand with durable V head, suitable for pipes ranging from 1/8-12 inches (3.2-304.8cm)
- Corrosion and dust resistant steel structure, allowing the weight of 2500lb (1134kg).
- Adjustable structure: Three stands with different height adjustment range from 50.5 to 132cm to support pipe for a variety of uses. Locking ring allows for quick vertical height adjustments.
- Folding and portable design: Foldable stand well saves the space, and its slip resistant rubber handle is easy to carry.
- Strong stability: The tripod design allows excellent stability. And tension plate supplies good horizontal supporting. Besides, it also has widened round foot pads.
Application
- Description: V head pipe stand
- Height adjustment(in.): 20-36 ½
- Low - High(mm): 50.5-93.5
- Max pipe capacity(in.): 12
- Max pipe capacity(mm): 300
- Max weight capacity(Lb.): 2500
- Max weight capacity(kg): 1134
- Weight(kg): 11.4
Model No.: 1107S
- Description: V head pipe stand
- Height adjustment(in.): 23-42 ½
- Low - High(mm): 60-108
- Max pipe capacity(in.): 12
- Max pipe capacity(mm): 300
- Max weight capacity(Lb.): 2500
- Max weight capacity(kg): 1134
- Weight(kg): 12.6
Model No.: 1107M
- Description: V head pipe stand
- Height adjustment(in.): 28-52
- Low - High(mm): 71-132
- Max pipe capacity(in.): 12
- Max pipe capacity(mm): 300
- Max weight capacity(Lb.): 2500
- Max weight capacity(kg): 1134
- Weight(kg): 14.4
Model No.: 1107L
| Catalog No. | 730010 | 730020 | 730030 | |
| Model No. | 1107S | 1107M | 1107L | |
| Description | V head pipe stand | V head pipe stand | V head pipe stand | |
| Height adjustment Low - High | in. | 20-36 ½ | 23-42 ½ | 28-52 |
| mm | 50.5-93.5 | 60-108 | 71-132 | |
| Max pipe capacity | in. | 12 | 12 | 12 |
| mm | 300 | 300 | 300 | |
| Max weight capacity | Lb. | 2500 | 2500 | 2500 |
| kg | 1134 | 1134 | 1134 | |
| Weight | kg | 11.4 | 12.6 | 14.4 |
Features
-
-
-
Three heights are available for a variety of uses.
-
-
-
-
Imported screws are of alloy materials.
-
-
-
Reliable and firm connection with bolts, and stable three-legged structure
-
-
-
Fastener allows a maximum weight of 2500lb.
-
-
-
Foldable design allows easy stocking and occupies small space.
