High-speed Disperser for Nanometer, LGF

Request a Quote

View All: http://longlygroup.com/3-2-high-speed-disperser-for-nanometer-lgf.html

This high speed disperser is a type of inline disperser for continuousoperation, which is typically designed for efficient dispersing andhomogenizing of nano-sized materials, which is widely used in variousindustries including new energy, coatings, cosmetics, food processing,LED light diffuser film, flexible PCB, etc. This dispersing system isespecially suited for preparation of positive and negative electrodeslurries for lithium ion batteries, as well as preparation of variousnanomaterials such as aluminum oxide, lithium titanate, conductivecarbon blacks and ternary composites in the nanometer scale.

Features

High frequency servo motor is used combining with compatible controlsystem, enable that the dispersing system works stably and reliablywhile ensures a long service life;
Individual design of dispersion wheel and vessel offers an excellentdispersing efficiency, especially suitable for ternary composites,graphene and graphene oxide that are difficult to disperse;
Patented cooling system allows that the materials are completelycooled during high-speed dispersion, fully satisfying customers’specific needs;
Cooling water of 5-7℃ is adopted for pre-cooling and dispersioncooling, ensuring the appropriate temperature of end products;

Schematic Diagram

Continuous Production of Battery Slurry in Chart

Specifications

Model	Motor Power (kW)	Throughput (L/H)	Rotating Speed	Control Method	Sealing Gas	Material of Dispersion Wheel	Material of Dispersion Vessel	Pump	Weight (kg)	Overall Dimension LxWxH (mm)
LGF-15	11	15	0-15000	Touch screen	Dry gas or nitrogen gas	SUS 304 / high-performance ceramic		Screw pump	200	500x600x1200
LGF-60	25	60	0-10000						850	900x1100x1900
LGF-240	55	240	0-6000						1000	1100x1200x2200
LGF-600	90	600	0-5000						1150	1300x1400x2400
LGF-900	120	900	0-4000					Diaphragm pump	1300	1300x1400x2400
LGF-1200	140	1200	0-3000						1550	1400x1500x2600
LGF-1500	150	1500	0-2600						1800	1500x1600x2800
