PE60x100, PE 100x150, PE 125x150 Jaw Crushers
Request a Quote
View All: http://tbttek.com/3-9-jaw-crushers.html
PE series jaw crushers are widely used to crush cement clinker, ore or rock specimens in laboratories. Jaw plates are made of Manganese steels for wear resistance.
If feed particle size is larger than 60mm, please choose 100x150 jaw crushers.
If feed particle size is smaller than 60mm, please choose 125x100 jaw crushers.
Model 150*200, 250*400 are available
Technical Parameters
| Model | PE 60x100 | PE 100x150 | PE 125x150 |
| Inlet size | 100x60mm | 100×150mm | 125x150mm |
| Feed particle size | ≤45mm | ≤80mm | 100mm |
| Final particle size | 3~15mm | 5mm | 6mm |
| Capacity | 45~550kg/h | 0.5~1.5T/h | 0.5~3T/h |
| Motor power | 1.5kW | 3kW | 4kW |
| Dimensions | 1050x430x820mm | 1050×500×700mm | 1200×550×900mm |
| Weight | Around 225kg | 260kg | 410kg |
