Jaw Crusher

Jaw Crusher
Request a Quote

The PE series of jaw crusher is mainly used for the coarse and medium crushing operations of various ore materials with compressive strength not exceeding 320Mpa. Featuring simple structure, reliable running, easy maintenance, low operating costs, large crushing ratio, and uniform size of processed material, this product is widely used in the mining, smelting, building material, highway, railway, water conservancy, chemical, and other industries.

Working Principle

The eccentric shaft is driven to rotate by the motor through the pulley, making the moveable jaw approach and leave the fixed jaw periodically, so as to squeeze, rub, and grind the material. Consequently, the material becomes smaller and gradually falls until it is discharged from the discharge port.

Technical Parameters of Jaw Crusher
Model Max. Feed Size
mm
Adjustment range of discharge opening
mm
Processing Capacity
m3/h
Motor Power
kW
Weight(Excluding motor)
t
PE-60×100 45 3-10 0.2-0.6 1.1 0.16
PE-150×250 125 10-40 0.6-3 5.5 0.81
PE-250×400 210 20-80 3-13.1 15 2.8
PE-250×500 210 20-80 5.7-31 18.5 3.37
PE-400×600 340 40-100 10-40 30 6.5
PE-430×600 400 90-140 35-60 37 6.5
PE-475×1050 400 90-140 37.5-81 55 11.7
PE-500×750 425 50-100 28.5-62.5 55 10.3
PE-550×900 450 50-120 47-75 55 7.8
PE-600×750 500 150-200 50-100 55 12
PE-600×900 500 65-160 30-75 55-75 15.5
PE-620×900 500 95-145 31-70 55-75 14.3
PE-670×900 520 195-245 66-83 55-75 14.8
PE-720×900 520 195-245 66-83 55-75 14.8
PE-750×1060 630 80-140 72-130 110 29.3
PE-800×1060 640 100-200 85-143 110 30
PE-870×1060 660 200-260 181-210 110 30.5
PE-900×1060 685 230-290 100-250 110 31
PE-900×1200 750 95-165 87-164 110 50
PE-1000×1200 850 195-265 197-214 110 50.6
PE-1100×800 650 50-125 38-156 132 19.86
PE-1200×1500 1000 150-300 250-500 220 82.3
PE-1500×1800 1200 220-350 281-625 280 122
PE1600×2100 1250 175-300 870-1500 355 169
