High Speed Label Slitting and Rewinding Machine, FQ-320/450
FQ-320/450 slitting and rewinding machines have been sold more than 5 thousands units until now. As the oldest machine since our establishment, it’s the amazing machine as the label finishing machine.
The slitting and rewinding machine has two web guide sensors from Taiwan brand for paper feeding, one Sick sensor from France for length and pcs counting, 1 set slitting blade (10 replaceable blades), and also can install shear knife for film slitting. Basic slitting and rewinding machine is equipped with two 3 inch shafts, but also can be equipped with 1.5 inch or 1 inch shaft.
The speed of the slitting and rewinding machine is 200m/min, and the weight is 500kg. If you interested in our slitter rewinder machine, please feel free to contact us.
| Model | FQ-320/450 |
| Max. web width | 320mm/450mm |
| Max. rewinding diameter | 500mm |
| Min. slitting width | 16mm |
| Slitting accuracy | ±0.15mm |
| Slitting speed | 85m/min |
| Overall dimensions (LxWxH) | 1500x1000x1200mm |
| Machine weight | 430kg |
-
-
- Option: Tensioning with magnetic brake & clutch
-
-
- Taiwan brand photoelectric sensor for material handling
-
-
- Slitting unit with counting rule
-
-
- SICK photoelectric sensor from France for counting pcs and meter
-
-
- Control panel
