MEVS Magnetic Speed Sensor

Request a Quote

View All: http://solution-sensor.com/4-1-mevs-magnetic-speed-sensor.html

Speed sensing solutions, Sensor solutions

YUANBEN’s MEVS magnetic speed sensor is made of a magnetoresistance sensor chip and metal housing. It is used to detect the position and rotation speed of magnetic conductive gear teeth. The magnetic rotation speed sensor features a high response frequency, high accuracy, excellent anti-interference, compact packaging, easy mounting, high reliability and wide detecting temperature range, making it applicable in a variety of industries, including textile, transport, metallurgy, chemistry, aerospace, automotive, robotics and machinery.

Technical Parameters

Model	MEVS-2-2. 4-M I 2	MEV S-2-2.4-M I 0
P/N	VS-08	VS-06A
Power Voltage	No	No
Short Circuit Protection	yes	yes
Output Signal	sine wave	sine wave
Output Voltage	proportional to target speed	proportional to target speed
Output Current	20mA	20mA
Output Resistance	1.7KΩ±10%	1.0 KΩ±15%
Output Inductance	400mH±20%	250mH±20%
Testing Speed Range (RPM)	40-6000RPM	40~6000RPM
Frequency	10kHz	10kHz
Rotational Direction of Gear	No	No
Working Air-Gap	0.5-2.0mm	0.5-2.0mm
Insulate Resistance	100MΩ	100MΩ
Housing Code	M12*50	M1032
Direction of Sensor Mounting	No	No
Cable	500mm	500mm
Temp. Range	-40~-125℃	-40~-125℃
Protection Class	IP65	IP65
Material of testing Target	Low carbon steel	Low carbon steel
Gear Type	60 teeth, gear module: 2	60 teeth, gear module: 2

Dimension

Applications

The MEVS sensor directly senses rotating ferrous gears such as web speed gears, power transmission gears, conveyor and other similar gear-based shaft encoders.

RPM/speed detectors (motor control)
Position sensors (as low as .002" detection)
Pulse counters (printers, motor drives)
Current sensing (motor control systems)
Banking machines (automatic tellers).
Telecommunications (on/off hook detector)
Shaft position sensors
Crankshaft position sensor
