1.5PF | 2-12ml/r
Hydraulic Gear Pump
Within the diverse lineup offered, ten gear pump series provide a displacement range from 0.16 to 199 ml/r, fulfilling a broad spectrum of requirements. The 1.5PF series emerges as a versatile solution, catering to applications requiring displacement from 2 to 12 ml/r, adaptable for both simple and complex system configurations.
Key attributes of the 1.5PF series
- Flexibility in displacement options from 2 to 12 ml/r, suited for a variety of system needs.
- Incorporates automatic axial clearance compensation, ensuring sustained performance and durability.
- Precision engineering with imported CNC machining equipment, highlighting a commitment to quality.
- Notable for its dependable quality and consistent operation, the 1.5PF series aligns with the highest standards of hydraulic product excellence.
| Model | Displacement (ml/r) | Pressure(bar) | Speed(r/min) | |||
| Rated | Peak | Rated | Max. | Min. | ||
| 1.5PF02F50F13S3* | 2 | 210 | 250 | 2000 | 3500 | 600 |
| 3 | 210 | 250 | 2000 | 3500 | 600 | |
| 4 | 210 | 250 | 2000 | 3500 | 600 | |
| 5 | 210 | 250 | 2000 | 3500 | 600 | |
| 6 | 210 | 250 | 2000 | 3500 | 600 | |
| 8 | 210 | 250 | 2000 | 3500 | 600 | |
| 9 | 175 | 210 | 1500 | 2000 | 600 | |
| 11 | 175 | 210 | 1500 | 2000 | 600 | |
| 12 | 175 | 210 | 1500 | 2000 | 600 | |
The 1.5PF series gear pumps represent a unique segment within our offerings, currently featuring two models tailored for distinct applications: one designed specifically for injection molding machines and the other for rice transplanters. This specialization underscores the series' adaptability and precision in meeting the needs of highly specific machinery, enhancing the performance and efficiency of specialized equipment across industries.
