Magnesium Rock Wool Sandwich Panel
Request a Quote
Magnesium rock wool sandwich panels use a high quality, color painted steel sheet as the face material, moisture resistant magnesium as the core material, a galvanized steel strip as the side seals and reinforcing ribs, and rock wool as the inner core materials. It is processed using compression, heating and other treatments for a strong load capacity, excellent sealing property, and outstanding fire rating.
Main features
- Bending and compression resistant with a maximum bearing capacity of 1000N/O. Magnesium rock wool sandwich panels can be used as both an envelope enclosure and bearing structure.
- The modular design is flexible and easy to install.
- Thermal insulation: thermal conductivity ≤0.048w/(m.K), meeting the 1-hour fire rating requirement.
Technical specs
Length: can be customized based on customer requirements (generally≤8000mm)
Width: standard: 900mm, 980mm, 1160mm, 1180mm; non-standard can be customized
Thickness: 40mm - 100mm
