Manhole Cover Testing Machine
Request a Quote
Model: TBTWC-1000A
TBTWC-1000A compression testing machine is used to test bearing capacity and residual deformation of manhole cover made of various materials. This compression testing machine is driven by hydraulic system which is close-loop controlled by computer servo technology.
Technical Parameters
| Max. compression capacity | 1000kN |
| Accuracy | Better than Grade 1 |
| Relative error | ±1% |
| Effective measuring range | 1%-100%F·S |
| Deformation relative error | ±1% |
| Deformation measuring resolution | 0.001mm |
| Max. distance between compression platens | 400mm |
| Effective distance between columns | 1200mm |
| Piston stroke | 380mm |
| Max. speed of piston moving | 80mm/min |
| Size of upper platen | Φ300mm |
| Size of lower platen | Φ356mm |
| Power | 1.8kW (pump motor: 1.5kW) |
| Loading frame dimension | 1420x1250x2120mm |
| Control cabinet dimension | 800x600x1600mm |
| Weight | Around 3000kg |
