Electric Vacuum Conveyor
Request a Quote
Features
- The electric vacuum conveyor features a simple structure that takes up very little space, emits low noise levels, and offers an easy operation.
- This conveyor eliminates material static electricity.
- The electric vacuum conveyor prevents transported materials from layering, thus ensuring the uniformity of mixed materials.
- This vacuum conveyor features a high negative pressure and large air flow, making it especially suitable for transportation of heavy materials over long distances or in large conveyance volumes.
Application
- It is suitable for transportation of food, medicine, and granular products like sugar, gluten, flour, medicine, rice, and more.
Technique specification
| Model | SK-SZK1D | SK-SZK2D | SK-SZK3D | SK-SZK4D |
| Conveying capacity | 100-400kg/h | 300-700kg/h | 600-1200kg/h | 1200-2500kg/h |
| Air pressure | 0.6Mpa | 0.6Mpa | 0.6Mpa | 0.6Mpa |
| Total power | 380V,50/60HZ,3kW | 380V,50/60HZ,5.5kW | 380V,50/60HZ,5.5kW | 380V,50/60HZ,7.5kW |
| Vacuum pump | Vortex gas pump | Vortex gas pump | Roots blower | Roots blower |
If you are interested in Soonk’s electric vacuum conveyor, please feel free to contact us!
