LHST195-24 Fine Wire Drawing Machine with Annealers
Request a Quote
Descriptions
The LHST195-24 fine wire drawing line is equipped with an annealer for superior mechanical performance. The minimum diameter of the finished wire is 0.1mm. The metal wire achieves better elongation performance thanks to the annealing process as its internal structure is enhanced. The maximum number of dies is up to 24.
| Model | LHS195-24B |
| Inlet wire diameter | φ0.60-φ1.20mm |
| Finished wire diameter | φ0.10-φ0.32mm |
| Max. line speed | 1000-2000m/min |
| Number of drawing dies | 24（1+11+11+1） |
| Cross section reduction | 13% - 15% |
| Lubrication method | Lubricant spraying (flat fan) |
| Total power | 20kW + 18kW |
| Motor power | 15/5.5kw |
| line arrangement | Ball screw driven by servo motor to rotate take-up axis |
| Take-up bobbin diameter | φ300×270×φ215×250×φ125mm |
| φ400×304×φ270×280×φ127mm | |
| Machine dimension | 2500×2000×2000mm（L×W×H） |
| Machine weight | 2.5t |
| Max. take-up bobbin weight | 50-100kg |
| Display | Touch screen |
