CD-280 30-120pcs Automatic Wet Wipe Packing Machine
Advantage
1. CD-280 30-120pcs automatic wet wipe packing machine is fitted with touch-screen for direct setting of product length, punching placement and label placement. As a result, customers avail from ease of operation and minimized possibility of human error.
2. Our wet wipe manufacture equipment involves the use of servomotor, showing the best in terms of running stability, noise generation, production rate and precision.
3. This paper product packing machine is equipped with a printer, allowing for convenient production date and code printing.
4. Thanks to fixed bag forming device, customers are provided with easy change of product size.
5. Corner inserting device is available in this automatic wet wipe packing machine to offer more aesthetic appearance.
| Power supply | 380V 50HZ |
| Power | 8kW |
| Production rate | 30 to 50 packs per min |
| Product size | (180 to 300) × (90 to 120) × (30 to 80)mm (L × W × H) |
| Controlling system | PLC, colorful touch-screen |
| Applicable material | OPP/PE, PET/PE |
| Machine weight | 1900kg |
| Machine dimension | 5280 × 1000 × 2100mm (L × W × H) |
| Option | Label protection tape device |
Workflow
Film package roll → printing date → punching hole on film package → sticking label → feeding on conveying belt → middle sealing → ends sealing and cutting → finished product output
