High frequency RFID tag can be used as the label of NFC card. NFC card is a short-range and wireless connectivity solution with high private. It can be widely used in various fields including access control, public transportation, mobile payment, etc.

NFC cards are compatible with existing contactless smart card technology has become more and more major vendors support the official standard. Our NFC cards can be customized on sizes, materials, surface patterns and so on according to your requirements.

● Basic parameters
Types	High-frequency passive RFID tags
Working frequency	13.56MHz
Protocol ISO14443A
● Physical parameters
Size	86 * 54 * 0.8mm or customized
Packaging Materials	PVC, PET
Antenna	Aluminum etching antenna, copper coil
Craft	4C Offset Printing, silk screen printing, stamping, encoding, anti-metal, with adhesive
● Performance parameters
Chip	NTAG213, NTAG216
Storage	Related to the chip
Operating mode	Can read and write
Data retention	> 10 years
Endurance	100,000 times
Reading distance	0-5cm (the reading range is related to the working condition and reader)
● Environmental parameters
Working temperature	-25 ℃ ~ + 55 ℃
Storage temperature	-35 ℃ ~ + 70 ℃
● Typical applications
Applications	Access control, membership management, mobile payment, products management
● Packaging
Packaging Information	Piece / Roll
