Grain Harvester (Combine Harvester with Grain Header)
Request a Quote
YTO-4LZ-9B1
Features
- Reliable – the high-strength frame made of 16Mn rectangular steel tube reduces damage of vibration; the transmission system applies Peer’s bearings and quality belts that have long service life; the hydraulic system consisting of “one hydraulic pump and one motor” is stable and dependable.
- Efficient – the high-pressure common rail multimode engine provides high horsepower with low fuel consumption; the rubbing thresher effectively separates grains from chaff and straw.
- Comfortable – the cab equipped with a suspension seat and an electromagnetic control lever gives you smooth and convenient control; color display helps you monitor the operation;
- Versatile: It can be equipped with multiple implements for a variety of uses, such as, corn and bean harvest.
- High-speed rubbing thresher
- Enhanced blower
- Long sieve that reduces grain loss
- Dual-channel unloader system for wheat and beans
- Suspension seat
- Hydraulic clutch for traveling
Specifications
| Model | 4LZ-9B1 |
| Dimensions (L*W*H) (mm) | 7160*3200*3420 |
| Weight (kg) | 5900 |
| Engine power (kW) | 139.7 |
| Minimum ground clearance (mm) | 280 |
| Cutting width (mm) | 2750 |
| Feeding rate (kg/s) | 9 |
| Harvesting speed (km/h) | 0.7～9.8 |
| Harvesting output (hm2/h) | 0.4～1.08 |
| Operating device | electromagnetic control lever/multifunction lever |
| Driving mode | Hydrostatic drive/mechanical transmission |
| Grain tank size (m³) | 2.5 |
| Fuel capacity (L) | 320 |
